Shelly Plus 1PM

Shelly Plus 1PM is new generation of WiFi-operated relay switch, 1 channel 16A, with Power Metering. It controls and measure power consumption for wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated relay switch, with Bluetooth connectio.

Shelly Plus 1PM is compatible with Amazon Alexa, Home Assistant, Smart Things and other 3rd party home automation platforms. Shelly Plus devices can also be grouped with all Shelly devices, as well as other smart home devices on the home network.

*Shelly Plus 1PM does not require a Hub device.

Functionalities :

• Wi-Fi operated – Connect Shelly Plus 1PM to your Wi-Fi network. No HUB required
• Bluetooth- Add devices quickly and easy via Bluetooth connection, using Shelly Cloud App
• Wide range of voltages supported – Shelly Plus 1PM can be powered by 110-240 VAC and 24 VDC
• Power metering with data storage – Shelly Plus 1PM provides precise monitoring of the power consumption
• Extremely fast processor – For immediate command execution and notification
• Enhanced safety – Enhanced over-temperature protection with software thresholds for control and prevention of failures
• Enhanced security – MQTT and WSS support, TLS and custom certificates support for a broad range of use cases
• Improved API interface – Broad range of cloud connections and local integrations with much lower integration cost

Technical Characteristics:

• Power supply AC: 110-230V ±10%, 50/60Hz
• Power supply DC: 24 V
• Dry contacts: No
• Roller shutter mode: No
• Device temperature protection: Yes
• Overload protection: Yes
• Power measurement: Yes
• Working without a neutral line: No
• Channels: 1 Channel
• Maximum load: 16A
• Operational temperature: 0°C to + 40°C
• Device power consumption: < 1 W
• Intelligent On/Off: Yes
• Local and remote control: Yes
• Sunrise/Sunset: Yes
• Weekly Schedule: Yes
• UL Listed option: No
• Wireless: Yes
• Wi-Fi Protocol: 802.11 b/g/n
• Wi-Fi Radio frequency: 2412 – 2484 MHz
• Wi-Fi Radio signal power: 1mW
• Wi-Fi Range: up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
• Bluetooth: Yes
• Size: 41mm x 36mm x 15mm
